| Product Name | AMD Radeon RX Vega M Graphic Card Gaming PC |
| Item NO. | F9 |
| Weight | 2.5 kg = 5.5116 lb = 88.1849 oz |
| Category | Mini PC |
| Tag | gaming pc , AMD Radeon RX Vega M |
| Brand | HYSTOU |
| Creation Time | 2021-10-16 |
Hystou Technology Co Limited is a reliable manufacturer and exporter of Mini PC. Our products are exported to the EU, America, Asia, etc., and have enjoyed a great reputation in the whole world market.This is HYSTOU latest gaming PC F9.
Product Highlight of F9 Mini PC:
- High Performance: Intel Core i7 i5 CPU with AMD Radeon RX Vega M GH Graphics. Dual Channel 64GB of DDR4 RAM (2 x 32Gb) and 2 x M.2 SSD drive. Preinstalled with Windows 10 Pro 64-Bit.
- Smart and Elegant Mini PC Form Factor: Easy to Setup, Easy to Upgrade, Easy to Configure. Multiple Usage Scenarios: Gaming, Office Work, Media Center, Mini Server, Education, Digital Signage.
- Energy and Space Efficient: Saves Desk Real Estate and Consumes Less Energy than Equivalent Alternatives. Almost Silent Operation Using Smart Fan and Smart Airflow Design. Aluminum Alloy + ABS Plastic.
- Plenty of Ports and Connectors: 4 x USB 3.0 port, 4 x USB 2.0 port, 1 x Type C USB 3.1 port, 2 x HDMI +2 x Mini DP 4 display output, 2 Gigabit Ethernet, Inside m.2 Wifi & Bluetooth Combo, 3.5mm Audio Jack. High Definition 4K 4 Displays Simultaneously.
- Certifications and Support: FCC, CE, ROSH, certifications. 24/7 Support. Functions: RTC wake up / Wake on Lan / Auto Power on (BIOS setting) / Network boot.
F9 Mini PC Specification:
|
Processor |
|
|
CPU |
Intel® Core™ i5-8305G Processor (6M Cache, 4 Cores 8 Threads, Base Frequency 2.80 GHz Turbo Frequency 3.80 GHz) Intel® Core™ i7-8705G Processor (8M Cache, 4 Cores 8 Threads, Base Frequency 3.10 GHz Turbo Frequency 4.10 GHz) Intel® Core™ i7-8709G Processor (8M Cache, 4 Cores 8 Threads, Base Frequency 3.10 GHz Turbo Frequency 4.10 GHz) Intel® Core™ i7-8809G Processor (8M Cache, 4 Cores 8 Threads, Base Frequency 3.10 GHz Turbo Frequency 4.20 GHz) |
|
TDP |
65~100W |
|
Chipset |
Intel Q150 |
|
CPU Lithography |
14 nm |
|
Memory Specifications |
|
|
Max Memory Size |
64GB |
|
Memory Types |
2*DDR4 SO-DIMM 260 pin |
|
Memory Speed |
2666 MHz |
|
Memory Channels |
Dual Channels |
|
ECC Memory |
Don’t support |
|
Storage Specification |
|
|
m.2 SSD |
2*M.2 2280 M KEY PCIE3.0 |
|
SATA |
NO SATA slot |
|
mSATA |
NO mSATA slot |
|
Graphics |
|
|
Processor Graphics |
Radeon™ RX Vega M GL for i5-8305G/i7-8705G,Radeon™ RX Vega M GH for i7-8709G/i7-8809G |
|
HDMI |
2*HDMI 4096*2160@60Hz(4K) |
|
Mini DP |
2*Mini DP 4096*2160@60Hz(4K) |
|
Power Specification |
|
|
Adapter Output |
DC 19V/9.47A |
|
Adapter Input |
AC 100-240V, 50/60HZ |
|
Consumption |
150W |
|
Auto Power On |
Support Auto Power On Function |
|
In & Out interfaces |
|
|
USB Port |
4*USB 3.0 port,4*USB 2.0 port,1*Type-C USB port |
|
Audio |
1*3.5mm MIC in & SPK out |
|
Video |
2*HDMI 4096 x 2160@60Hz + 2*Mini DP 4096 x 2160@60Hz Support 4 Display Output |
|
SD Card |
1*SD Card reader slot |
|
Audio Cards |
USB Audio Device |
|
M.2 |
1*M.2 E KEY 2230 |
|
Lan Port |
1* RJ45 Lan Gigabit Ethernet Controller, Realtek 8168/8111 |
|
Wi-Fi |
Inside Wifi & Bluetooth Combo |
|
Others |
|
|
System |
Support Windows 10, Linux |
|
BIOS |
Support AUTO POWER ON,Wake On LAN,PXE |
|
Work Environment |
-10℃--60℃(14F~140F) , 30%--90% Humidity |
|
Case Material |
ABS + Aluminum Alloy |
|
Dimension |
PC size 225*146*52mm Package size 310*290*130mm |
|
Weight |
Net 1.2kg; Gross 2.3kg |
